S802E 8-Port PoE Switch, 96W, AI Watchdog, 300m Extend
S802E
Type Unmanaged AI PoE Switch
PoE Ports 8× 10/100Mbps (IEEE 802.3af/at)
Uplink Ports 2× 10/100Mbps RJ45
PoE Per Port Up to 30W (802.3at)
Total PoE Budget 96W (Built-in AC 100~240V)
5 Years Warranty
Overview
- 8× PoE ports (802.3af/at) — up to 30W per port, 96W total budget
- AI Extend mode — 300m long-distance PoE on Port 1
- AI Watchdog auto-reboots unresponsive PoE cameras and APs
- VLAN isolation across Ports 1–8 to eliminate broadcast storms
- Built-in AC 100~240V power supply — no external power bricks needed
- 2.0Gbps switching capacity with 4K MAC address table
- 4kV surge and ±15kV ESD protection
- Fanless metal enclosure — desktop and wall mount options
The S802E is a 10-port unmanaged AI PoE switch with 8× 802.3af/at PoE ports (30W each, 96W total), 2× uplink ports, and a built-in AC 100–240V power supply. Featuring AI Watchdog, 300m EXTEND mode, VLAN isolation, 2.0Gbps switching capacity, and 4kV surge protection in a fanless metal enclosure, it is designed for IP camera systems, wireless AP networks, VoIP deployments, and small enterprise environments.
Ideal For
- IP camera and NVR networks in schools, hotels, factories, and retail
- Wireless access point PoE power delivery in commercial spaces
- VoIP phone networks requiring reliable uninterrupted PoE
- Small office and enterprise LAN switch deployments
- Smart city monitoring infrastructure requiring AI self-healing
Deployment Advantages
The built-in 96W AC power supply eliminates the need for external PoE injectors or power bricks, simplifying installation and reducing the component count in network cabinets. The 2.0Gbps switching fabric with 4K MAC address table and 1.25MB buffer handles simultaneous HD camera streams and data traffic without congestion.
The 300m EXTEND mode on Port 1 enables long cable runs for remote cameras or APs, while VLAN isolation across all PoE ports prevents the broadcast storm issues common in large camera networks. AI Watchdog’s automatic power-cycle recovery keeps the network operational between maintenance visits without manual intervention.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product, including custom port configurations, power budget variations, enclosure branding, and private-label packaging. Volume pricing is available for surveillance integrators, IT distributors, and enterprise resellers. Contact us to discuss your project requirements.
Specifications
| Type | Unmanaged AI PoE Switch |
| PoE Ports | 8× 10/100Mbps (IEEE 802.3af/at) |
| Uplink Ports | 2× 10/100Mbps RJ45 |
| PoE Per Port | Up to 30W (802.3at) |
| Total PoE Budget | 96W (Built-in AC 100~240V) |
| Switching Capacity | 2.0Gbps |
| Forwarding Rate | 1.488Mpps |
| MAC Address Table | 4K |
| Extend Mode | Up to 300m @ 10Mbps (Port 1) |
| Surge Protection | 4kV, ESD ±8kV contact / ±15kV air |
| Enclosure | IP30 Metal, Fanless |
| Temperature | -20°C ~ +55°C |
Ordering & Customization
The S802E ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
What is the total PoE power budget of the S802E?
The S802E provides a 96W total PoE power budget with a built-in AC 100–240V power supply. Each of the 8 PoE ports supports up to 30W (802.3at), with an average of 15.4W per port across all ports under full load. The built-in PSU eliminates the need for external power adapters or PoE injectors.
How does VLAN isolation benefit camera network deployments?
VLAN isolation on the S802E segments each PoE port (1–8) from each other while allowing all ports to communicate with the uplink. This prevents broadcast storms common in camera networks, stops one compromised camera from affecting others, and simplifies network segmentation without requiring a managed switch.
Can the S802E be used for wireless access point deployments?
Yes. The S802E is well suited for PoE-powered wireless AP deployments in hotels, schools, offices, and retail environments. Each port's 30W capacity covers 802.3at APs, and the AI Watchdog automatically recovers APs that hang — reducing support calls in unmanned locations.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
What is the MOQ for the S802E?
Standard S802E orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the S802E before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the S802E?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the S802E certified for my market?
The S802E carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
