S402E 4-Port PoE Switch, 60W, AI Watchdog, 300m Extend
S402E
MOQ 100 units Lead time 3–4 weeks Samples 1–5 units 5 Years warranty
Type Unmanaged AI PoE Switch
PoE Ports 4× 10/100Mbps (IEEE 802.3af/at)
Uplink Ports 2× 10/100Mbps RJ45
PoE Per Port Up to 30W (802.3at)
Total PoE Budget 60W (Built-in AC 100~240V)
Overview
- 4× PoE ports (802.3af/at) — up to 30W per port, 60W total budget
- AI Extend mode — 300m long-distance PoE on Ports 1–4
- AI Watchdog auto-reboots unresponsive PoE cameras and APs
- VLAN isolation across Ports 1–4 to eliminate broadcast storms
- Built-in AC 100~240V power supply — no external power bricks needed
- 1.2Gbps switching capacity with 2K MAC address table
- ±4kV surge and ±15kV ESD protection
- Fanless metal enclosure — desktop and wall mount options
The S402E is a 6-port unmanaged AI PoE switch with 4× 802.3af/at PoE ports (30W each, 60W total), 2× uplink ports, and a built-in AC 100–240V power supply. Featuring AI Watchdog, 300m EXTEND mode on all PoE ports, VLAN isolation, 1.2Gbps switching capacity, and ±4kV surge protection in a fanless metal enclosure, it is designed for small IP camera systems, wireless AP networks, and compact office or retail network deployments.
Ideal For
- Small IP camera and NVR networks in retail stores, offices, and dormitories
- Wireless access point PoE power delivery in compact deployments
- VoIP phone networks requiring reliable uninterrupted PoE
- Small business LAN switch deployments with long cable runs
- Plug-and-play installations by non-technical staff or rapid integrators
Deployment Advantages
The built-in 60W AC power supply eliminates the need for external PoE injectors, simplifying installation and reducing component count. The 300m EXTEND mode on Ports 1–4 enables long cable runs for remote cameras or APs at 10Mbps — covering most small-site surveillance needs without additional equipment.
AI Watchdog automatically power-cycles unresponsive PoE devices, keeping cameras and APs online between maintenance visits. VLAN isolation prevents broadcast storms common in camera networks, and the compact fanless metal chassis supports both desktop and wall-mount installation in tight spaces.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product, including custom port configurations, power budget variations, enclosure branding, and private-label packaging. Volume pricing is available for surveillance integrators, IT distributors, and enterprise resellers. Contact us to discuss your project requirements.
Specifications
| Type | Unmanaged AI PoE Switch |
| PoE Ports | 4× 10/100Mbps (IEEE 802.3af/at) |
| Uplink Ports | 2× 10/100Mbps RJ45 |
| PoE Per Port | Up to 30W (802.3at) |
| Total PoE Budget | 60W (Built-in AC 100~240V) |
| Switching Capacity | 1.2Gbps |
| Forwarding Rate | 0.89Mpps |
| MAC Address Table | 2K |
| Extend Mode | Up to 300m @ 10Mbps (Ports 1–4) |
| Surge Protection | ±4kV, ESD ±8kV contact / ±15kV air |
| Enclosure | IP30 Metal, Fanless |
| Dimensions | 195 × 135 × 40 mm |
| Temperature | -20°C ~ +55°C |
Ordering & Customization
The S402E ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
What is the total PoE power budget of the S402E?
The S402E provides a 60W total PoE power budget with a built-in AC 100–240V power supply. Each of the 4 PoE ports supports up to 30W (802.3at). The built-in PSU eliminates the need for external power adapters or PoE injectors, making it a clean, compact solution for small surveillance or AP installations.
How does the 300m Extend mode work on the S402E?
Extend mode reduces the port speed to 10Mbps to enable PoE power and data transmission over cable runs up to 300 metres on Ports 1–4 — three times the standard 100m limit. This allows camera or AP placements far from the NVR or core switch without signal boosters or additional hardware.
Can VLAN isolation be used on the S402E?
Yes. VLAN isolation segments each PoE port (1–4) from each other while allowing all ports to communicate with the uplink. This prevents broadcast storms in camera networks, improves stability, and provides basic network segmentation without requiring a managed switch.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
What is the MOQ for the S402E?
Standard S402E orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the S402E before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the S402E?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the S402E certified for my market?
The S402E carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
