AP1800M AX1800 Wi-Fi 6 Outdoor Access Point, IP67
AP1800M
Wi-Fi 6 (802.11ax/ac/a/n/g/b) · Dual-Band (2.4GHz + 5GHz) · AX1800 (574 + 1201 Mbps) · 48V Active & Passive PoE
1 / 6
CE FCC RoHS
APM6-AX1800 AX1800 Wi-Fi 6 Outdoor Access Point, IP67
APM6-AX1800
Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX1800 (574 + 1201 Mbps)
CPU MT7621AT + MT7905N + MT7975DN
Antenna 4× 8dBi High-Gain Fiberglass Omni
5 Years Warranty
Overview
- Wi-Fi 6 dual-band AX1800 — 574Mbps @ 2.4GHz + 1201Mbps @ 5GHz
- IP67 weatherproof with 15kV ESD and 6kV lightning protection
- Four 8dBi high-gain fiberglass antennas for long-range coverage
- Mesh, AP, Router, Repeater, and AP+Repeater modes
- Seamless Wi-Fi roaming across multiple access points
- Supports 802.3AF/AT active PoE and passive PoE
- Low power consumption — ≤ 7W
- Operating range -40°C to +70°C for extreme environments
The APM6-AX1800 is a dual-band Wi-Fi 6 outdoor access point delivering AX1800 speeds (574 + 1201Mbps) in an IP67-rated enclosure. With four 8dBi high-gain fiberglass antennas, support for Mesh/AP/Router/Repeater modes, and 15kV ESD plus 6kV lightning protection, it is built for long-range outdoor coverage in demanding conditions.
Ideal For
- Rural communities and village-level outdoor Wi-Fi coverage
- Farms, campgrounds, and large residential outdoor areas
- Street-level and public square wireless hotspots
- Hotel and resort outdoor coverage extension
- Small campus and school perimeter networks
Deployment Advantages
The four 8dBi fiberglass omnidirectional antennas, combined with dual built-in high-power amplifiers, provide exceptional signal range and penetration for open outdoor environments. IP67 protection goes beyond the standard IP65 rating, ensuring the device remains fully sealed against dust ingress and water immersion — suitable for coastal or high-humidity climates.
Multi-mode support (Mesh, AP, Router, Repeater) means the same hardware can serve different network topologies without additional equipment. The ≤7W power consumption and PoE compatibility make it cost-effective for battery-backed or solar-powered outdoor installations.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product, including custom firmware, antenna specification changes, enclosure branding, and private-label packaging. Volume pricing is available for ISPs, community Wi-Fi operators, and system integrators. Our wireless access point ODM program covers firmware, antenna, and enclosure customization with MOQs from 100 units. Contact us to discuss your project requirements.
Specifications
| Standard | Wi-Fi 6 (802.11ax) |
| Band | Dual-Band (2.4GHz + 5GHz) |
| Max Speed | AX1800 (574 + 1201 Mbps) |
| CPU | MT7621AT + MT7905N + MT7975DN |
| Antenna | 4× 8dBi High-Gain Fiberglass Omni |
| Ethernet | 1× GbE WAN (PoE) |
| PoE | 802.3AF/AT Active + Passive PoE |
| Enclosure | IP67 Outdoor Rated |
| Working Mode | Mesh / AP / Router / Repeater |
| Power Consumption | ≤ 7W |
| Temperature | -40°C ~ +70°C |
Ordering & Customization
The APM6-AX1800 ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
What wireless modes does the APM6-AX1800 support?
The APM6-AX1800 supports Mesh, AP, Router, Repeater, and AP+Repeater modes. This flexibility allows it to function as a primary gateway, range extender, or mesh node — making it adaptable to both simple home networks and large-scale outdoor mesh deployments.
How far can the APM6-AX1800 cover outdoors?
Equipped with four 8dBi high-gain fiberglass omnidirectional antennas and dual built-in high-power amplifiers, the APM6-AX1800 delivers long-range outdoor coverage suitable for farms, campuses, communities, and street-level installations, with signal penetration optimized for open environments.
What are the power supply options?
The APM6-AX1800 supports 802.3AF/AT active PoE and passive PoE, enabling cable runs up to 100m (CAT5e or above) for installations where mains power is unavailable. It can also be powered via 12V DC adapter.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
What is the MOQ for the APM6-AX1800?
Standard APM6-AX1800 orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the APM6-AX1800 before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the APM6-AX1800?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the APM6-AX1800 certified for my market?
The APM6-AX1800 carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
