APH4-BE3600 Wi-Fi 7 Outdoor AP, 2.5G Port, IP65, PoE
APH4-BE3600
Type Outdoor Wi-Fi 7 Access Point
Standard Wi-Fi 7 (802.11be), 2.4GHz + 5GHz
CPU AN7563 + MT7991B + MT7976CN + EN8811H
Memory 128MB Flash + 512MB RAM
Max Speed 3600Mbps (688 + 2882 Mbps)
5 Years Warranty
Overview
- Wi-Fi 7 (802.11be) dual-band 3600Mbps — 688Mbps on 2.4GHz + 2882Mbps on 5GHz
- Next-gen AN7563 + MT7991B chipset for ultra-low latency and high efficiency
- 1× 2.5Gbps WAN port for high-bandwidth backhaul connections
- Supports up to 128 concurrent clients with 80m coverage radius
- IP65 UV-resistant weatherproof enclosure for harsh outdoor environments
- Dual power: 802.3at PoE or DC 12V for flexible installation
- Cloud and app management for centralized multi-site control
- Pole and wall mounting options included
The APH4-BE3600 is a next-generation Wi-Fi 7 outdoor access point delivering 3600Mbps dual-band performance (688Mbps on 2.4GHz and 2882Mbps on 5GHz) powered by the AN7563 + MT7991B + MT7976CN + EN8811H platform. With a 2.5Gbps WAN port, 128 concurrent client support, IP65 weatherproof UV-resistant enclosure, and 802.3at PoE or DC 12V power input, it is designed for hotel outdoor areas, campus perimeters, enterprise courtyards, and dense outdoor Wi-Fi deployments.
Ideal For
- Hotel outdoor areas, poolside, and resort perimeter Wi-Fi deployments
- Campus and university outdoor common areas requiring high-density coverage
- Enterprise courtyards and parking areas with large numbers of connected devices
- Commercial outdoor events, markets, and public Wi-Fi hotspot infrastructure
- ISP outdoor CPE and wireless access deployments requiring next-gen performance
Deployment Advantages
Wi-Fi 7’s Multi-Link Operation and 4096-QAM modulation provide measurably higher throughput and lower latency per client compared to Wi-Fi 6 equipment at the same price point. The 2.5Gbps WAN backhaul ensures the wireless capacity is not bottlenecked by the uplink, which is critical for dense deployments with many simultaneous HD video streams or large file transfers.
The compact 196×86×40mm form factor and 0.4kg weight simplify pole or wall mounting. IP65 UV-resistant housing protects against rain, dust, and long-term solar exposure without discoloration or degradation.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product including custom firmware, enclosure branding, web management page branding, and custom packaging. A fully white-labeled cloud platform is not included by default and must be separately scoped on an eligible model with setup and committed-volume requirements. Volume pricing is available for hotels, ISPs, enterprise wireless integrators, and IT distributors. Contact us to confirm the program that matches your deployment.
Specifications
| Type | Outdoor Wi-Fi 7 Access Point |
| Standard | Wi-Fi 7 (802.11be), 2.4GHz + 5GHz |
| CPU | AN7563 + MT7991B + MT7976CN + EN8811H |
| Memory | 128MB Flash + 512MB RAM |
| Max Speed | 3600Mbps (688 + 2882 Mbps) |
| Antenna | 2×2.4GHz + 2×5GHz Omnidirectional, 5dBi |
| Max Clients | 128 concurrent |
| WAN | 1× 2.5Gbps (PoE IN) |
| LAN | 1× 1Gbps |
| Power | DC 12V/2A or 802.3at PoE |
| Power Consumption | <20W |
| Coverage | 80m radius |
| Enclosure | IP65, UV-resistant |
| Dimensions | 196 × 86 × 40 mm |
| Weight | 0.4 kg |
| Temperature | -30°C ~ +55°C |
Ordering & Customization
The APH4-BE3600 ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
What makes Wi-Fi 7 better than Wi-Fi 6 for outdoor deployments?
Wi-Fi 7 (802.11be) introduces Multi-Link Operation (MLO), 4096-QAM modulation, and up to 320MHz channel bandwidth, resulting in significantly higher throughput, lower latency, and better performance in high-density environments compared to Wi-Fi 6. The APH4-BE3600 uses these advances with a 2.5Gbps WAN port to ensure the backhaul doesn't bottleneck the wireless performance.
Is OEM/ODM customization available for this product?
Yes. MossLink offers custom firmware, enclosure branding, web management page branding, and private-label packaging. A fully white-labeled cloud platform is available only as a separately scoped OEM program on selected models, with setup and committed-volume requirements.
What is the MOQ for the APH4-BE3600?
Standard APH4-BE3600 orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the APH4-BE3600 before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the APH4-BE3600?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the APH4-BE3600 certified for my market?
The APH4-BE3600 carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
