YA795 AC1200 Outdoor Wi-Fi Access Point, IP65, PoE
YA795
Standard Wi-Fi 5 (802.11ac)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AC1200 (300 + 900 Mbps)
CPU MT7628DAN + MT7613
RAM 64MB DDR2
5 Years Warranty
Overview
- Dual-band AC1200 — 300Mbps @ 2.4GHz + 900Mbps @ 5GHz
- OpenWRT-compatible firmware for advanced customization
- IP65 weatherproof plastic housing for outdoor use
- 2× replaceable 6dBi SMA omni antennas, 100–150m coverage
- Supports multi-SSID (up to 8), seamless roaming, and load balancing
- 24V PoE adapter included for remote power delivery
- Low power RF output (100mW) for compact outdoor installations
- Cloud remote access and WLAN controller management support
The YA795 is a dual-band AC1200 outdoor access point with IP65-rated weatherproof housing, two replaceable 6dBi SMA omnidirectional antennas, and support for both QSDK and OpenWRT firmware. With a 24V PoE adapter included and up to 100–150m coverage radius, it is a cost-effective and highly customizable solution for garden, farm, park, and small outdoor hotspot deployments.
Ideal For
- Gardens, farms, and rural residential outdoor coverage
- Parks, scenic spots, and public squares
- Small campuses and school perimeter access points
- Community outdoor Wi-Fi hotspot installations
- Deployments requiring OpenWRT for custom firmware
Deployment Advantages
SMA connectors on both antennas allow field replacement or upgrade to higher-gain antennas without specialized tools, providing deployment flexibility when coverage requirements change. The included 24V PoE adapter enables cable runs up to 100m, making it practical for pole-mounted outdoor installations far from power outlets.
Multi-SSID support (up to 8 SSIDs) with seamless roaming and intelligent load balancing allows the YA795 to serve multiple tenant networks or segment traffic by user type — useful for hotel gardens, campground zones, or small ISP outdoor hotspots. WLAN controller and cloud management support enables centralized administration of multiple units.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product, including QSDK or OpenWRT custom firmware builds, antenna specifications, enclosure branding, and private-label packaging. Review the OpenWrt customization guide for hotspot authentication, RADIUS accounting, traffic control, regional firmware, and fleet-management options. Volume pricing is available for ISPs, outdoor Wi-Fi operators, and system integrators. As an access point OEM factory, MossLink ships white-label outdoor APs with your firmware and branding. Contact us to discuss your project requirements.
Specifications
| Standard | Wi-Fi 5 (802.11ac) |
| Band | Dual-Band (2.4GHz + 5GHz) |
| Max Speed | AC1200 (300 + 900 Mbps) |
| CPU | MT7628DAN + MT7613 |
| RAM | 64MB DDR2 |
| Flash | 8MB |
| Antenna | 2× 6dBi SMA Omni (Replaceable) |
| Ethernet | 1× 100Mbps WAN + 1× 100Mbps LAN |
| PoE | IEEE 802.3af 24V PoE (included) |
| Max Clients | 80 (Recommended) |
| Enclosure | IP65 Outdoor Rated |
| Operating Mode | AP / Gateway / Repeater |
| Firmware | QSDK / OpenWRT |
| Power | 12V 1A DC |
Ordering & Customization
The YA795 ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
Does the YA795 support OpenWRT firmware?
Yes. The YA795 supports both QSDK and OpenWRT firmware, making it highly customizable for ISPs, system integrators, and developers who require open-source firmware with advanced routing, VLAN, and management features beyond standard factory firmware.
What is the outdoor coverage range of the YA795?
The YA795 achieves a coverage radius of 100–150 metres using the standard 6dBi SMA omnidirectional antennas. The SMA connectors allow upgrading to higher-gain antennas for extended coverage in specific deployment scenarios.
What makes the YA795 suitable for gardens, farms, and parks?
The IP65 weatherproof enclosure, pole and wall mounting options, and 24V PoE power delivery make the YA795 easy to deploy in outdoor locations without mains power access. Its compact size and low power consumption make it cost-effective for small-to-medium outdoor installations.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
What is the MOQ for the YA795?
Standard YA795 orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the YA795 before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the YA795?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the YA795 certified for my market?
The YA795 carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
