APM2-AC1200 AC1200 Wi-Fi 5 Outdoor Access Point, IP67

APM2-AC1200

Standard Wi-Fi 5 (802.11ac/a/n + 802.11b/g/n)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AC1200 (300 + 867 Mbps)
CPU MT7628DAN + MT7613BEN
Antenna 2× 7dBi High-Gain Omni
View all specifications → Datasheet

5 Years Warranty

Talk via WhatsApp

Specifications

Standard Wi-Fi 5 (802.11ac/a/n + 802.11b/g/n)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AC1200 (300 + 867 Mbps)
CPU MT7628DAN + MT7613BEN
Antenna 2× 7dBi High-Gain Omni
Ethernet 1× GbE WAN (PoE)
PoE 802.3AF/AT Active + Passive PoE
Enclosure IP67 Outdoor Rated
Working Mode AP / Router / Repeater / Client
Power Consumption ≤ 10W
Temperature -30°C ~ +70°C

Features

  • Wi-Fi 5 dual-band AC1200 — 300Mbps @ 2.4GHz + 867Mbps @ 5GHz
  • IP67 weatherproof enclosure with 6kV lightning and 15kV ESD protection
  • 2× 7dBi high-gain omnidirectional antennas for reliable outdoor coverage
  • AP, Router, Repeater, and Client modes for flexible deployment
  • Supports 802.3AF/AT active PoE and passive PoE
  • Operating range -30°C to +70°C for demanding outdoor environments
  • Low power consumption — ≤ 10W
  • Cost-effective entry point for outdoor Wi-Fi infrastructure
APM2-AC1200 IP67 weatherproof outdoor housing and antenna assembly
IP67 sealed enclosure with high-gain omnidirectional antennas — dust-tight and water-immersion rated for coastal and tropical climates
APM2-AC1200 lightning and ESD protection design
Built-in 6kV lightning and 15kV ESD protection guards against electrical events in open outdoor environments
APM2-AC1200 multi-mode deployment scenarios — AP, Router, Repeater, Client
AP / Router / Repeater / Client modes on a single SKU — covers campuses, courtyards, parking lots, and perimeter poles
APM2-AC1200 PoE and pole-mount installation
Single-cable PoE (802.3AF/AT or passive) simplifies rooftop and pole installations — no AC wiring required

The APM2-AC1200 is a dual-band Wi-Fi 5 outdoor access point delivering AC1200 speeds (300 + 867Mbps) in an IP67-rated enclosure. With two 7dBi high-gain omnidirectional antennas, 6kV lightning and 15kV ESD protection, and multi-mode support (AP / Router / Repeater / Client), it provides a reliable and cost-effective outdoor wireless solution for environments where 802.11ac performance is sufficient.

Ideal For

  • Budget-conscious outdoor Wi-Fi deployments for small communities and campuses
  • Courtyards, parking lots, and outdoor public spaces
  • Hospitality outdoor coverage — resorts, camps, and guesthouses
  • Last-metre coverage extension after a wireless bridge link
  • IoT and surveillance backhaul at perimeter poles and towers

Deployment Advantages

The two 7dBi omnidirectional antennas provide consistent 360° outdoor coverage, while IP67 protection seals the unit against dust ingress and water immersion — making it suitable for coastal, high-humidity, and tropical climates. The 6kV lightning and 15kV ESD protection guard against electrical events common in open outdoor environments.

Multi-mode operation means a single SKU covers AP, Router, Repeater, and Client deployments without firmware changes. PoE over a single Gigabit cable simplifies pole and rooftop installations where running AC power is impractical. The broad temperature range (-30°C to +70°C) ensures reliable operation from cold-climate winters to desert heat.

Cost-Effective Outdoor Coverage

The APM2-AC1200 is the entry-level outdoor AP in the MossLink APM series, making it the right choice when the deployment budget is tight or when connected client devices are predominantly 802.11ac. For installations that require Wi-Fi 6 performance or higher client density, see the APM6-AX1800 and APM6-AX3000.

OEM/ODM Ready

MossLink offers OEM and ODM customization for this product, including custom firmware defaults, enclosure branding, antenna configuration changes, and private-label packaging. Volume pricing is available for ISPs, system integrators, and community Wi-Fi operators. Contact us to discuss your project requirements.

Frequently Asked Questions

What wireless modes does the APM2-AC1200 support?
The APM2-AC1200 supports AP, Router, Repeater, and Client modes. This flexibility lets it function as a standalone access point, a range extender, or a wireless client bridge — covering a wide range of outdoor deployment scenarios without requiring additional hardware.
How far can the APM2-AC1200 cover outdoors?
Equipped with two 7dBi high-gain omnidirectional antennas and built-in amplifiers, the APM2-AC1200 provides reliable outdoor coverage suitable for small campuses, courtyards, parking lots, and community outdoor areas under clear line-of-sight conditions.
What are the power supply options?
The APM2-AC1200 supports 802.3AF/AT active PoE and passive PoE, enabling cable runs up to 100m (CAT5e or above). It can also be powered via a DC adapter, giving flexibility for solar-powered or off-grid outdoor installations.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware, enclosure branding, antenna configuration, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
How does the APM2-AC1200 compare to the APM6-AX1800?
The APM2-AC1200 runs Wi-Fi 5 (802.11ac) at AC1200 speeds — a cost-effective choice for deployments where budget is the primary constraint or where connected devices are predominantly older 802.11ac clients. The APM6-AX1800 upgrades to Wi-Fi 6 (802.11ax) with AX1800 speeds, OFDMA, and improved high-density performance. Both share IP67 outdoor protection and PoE support.
