X5-G30 Wi-Fi 6 Outdoor Bridge, 30dBi Grid, 2.5Gbps
X5-G30
Type Outdoor Long-Range PtP Wireless Bridge
Standard Wi-Fi 6 (802.11ax), 5.1–5.8GHz
CPU Dual-core ARM Cortex-A53 @ 1.0GHz
Antenna 30dBi High-Gain Grid, 11° Beamwidth
Channel Bandwidth 20/40/80/160MHz
5 Years Warranty
Overview
- 30dBi high-gain grid antenna with 11° beamwidth for ultra-long-range PtP links
- Wi-Fi 6 (802.11ax) with 160MHz channel bandwidth for maximum throughput
- Dual-core ARM Cortex-A53 for low-latency high-performance processing
- 1× 2.5Gbps + 1× Gigabit Ethernet for high-bandwidth backhaul
- 8kV surge protection and IP67 enclosure for harsh outdoor deployments
- WPA3-SAE enterprise security with VLAN 802.1Q support
- SNMP, TR069, SSH, HTTPS management for enterprise integration
The X5-G30 is a professional outdoor Wi-Fi 6 point-to-point wireless bridge with a 30dBi high-gain grid antenna and 11° beamwidth for ultra-long-range directional links. Built on a dual-core ARM Cortex-A53 platform with 160MHz channel support, 1×2.5Gbps and 1×Gigabit Ethernet ports, 8kV surge protection, and IP67 weatherproofing, it is designed for WISP backhaul, 4K/8K CCTV transmission, rural broadband, industrial networking, and ISP last-mile links requiring maximum link budget and enterprise management.
Ideal For
- Ultra-long-range PtP backhaul links for WISPs and ISPs
- 4K/8K IP camera and CCTV video transmission over long distances
- Rural village and remote facility broadband connectivity
- Mining, oilfield, mountain-to-valley, and industrial park networking
- Starlink and satellite internet extension to secondary buildings or sites
Deployment Advantages
The 30dBi grid antenna provides the highest gain in the X5 series, with a narrow 11° beamwidth that maximizes directional gain and minimizes interference from surrounding RF sources. The 160MHz channel width option with Wi-Fi 6’s OFDMA support delivers throughput levels previously requiring licensed microwave equipment.
The 2.5Gbps Ethernet port eliminates the wired bottleneck that limits Gigabit-only bridges when aggregating multiple HD video streams or serving as a WAN uplink for multi-AP networks. Combined with 8kV surge protection and IP67 sealing, the X5-G30 delivers long-term reliability in demanding field deployments.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product including custom firmware, enclosure branding, labels, and custom packaging. A fully white-labeled cloud platform is not a standard feature of this bridge. Volume pricing is available for WISPs, system integrators, and wireless equipment distributors.
Specifications
| Type | Outdoor Long-Range PtP Wireless Bridge |
| Standard | Wi-Fi 6 (802.11ax), 5.1–5.8GHz |
| CPU | Dual-core ARM Cortex-A53 @ 1.0GHz |
| Antenna | 30dBi High-Gain Grid, 11° Beamwidth |
| Channel Bandwidth | 20/40/80/160MHz |
| Ethernet | 1× 2.5Gbps + 1× Gigabit |
| Power | PoE 22–56V (802.3at) or DC 12V |
| Power Consumption | <15W |
| Surge Protection | 8kV |
| Enclosure | IP67 |
| Weight | 7.0 kg |
| Temperature | -30°C ~ +60°C |
Ordering & Customization
The X5-G30 ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Frequently Asked Questions
How far can the X5-G30 transmit reliably?
Under clear line-of-sight conditions, the X5-G30's 30dBi grid antenna with 11° beamwidth achieves reliable long-distance PtP links suitable for 20km+ deployments. Actual range depends on terrain, Fresnel zone clearance, and local RF conditions. For reference, the 30dBi gain provides approximately 6dB more link budget than a 24dBi dish of comparable aperture.
What management protocols does the X5-G30 support?
The X5-G30 supports HTTP/HTTPS web GUI, SNMP v1/v2/v3, TR069, SSH, and VLAN 802.1Q with 802.1p priority queuing. This enterprise feature set enables integration with existing NMS platforms and remote management at scale for ISP and enterprise deployments.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services including custom firmware, enclosure branding, and private-label packaging. Contact us to discuss your project requirements.
What is the MOQ for the X5-G30?
Standard X5-G30 orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the X5-G30 before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the X5-G30?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the X5-G30 certified for my market?
The X5-G30 carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
