APH5-AX830SFP Wi-Fi 6 Outdoor AP, SFP Uplink, 3000Mbps
APH5-AX830SFP
Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (574 + 2402 Mbps)
Antenna 2×2.4GHz + 2×5GHz External Omni, 5dBi each
Ethernet 1× GbE SFP + 1× GbE WAN (PoE 48V) + 1× GbE LAN
5 Years Warranty
Overview
- Wi-Fi 6 dual-band 3000Mbps with OFDMA and MU-MIMO
- Dedicated Gigabit SFP port for fiber backhaul
- Flexible interfaces: 1× GbE SFP + 1× GbE WAN + 1× GbE LAN
- IP65 UV-resistant weatherproof enclosure
- Up to 192 concurrent client connections
- Seamless roaming, VLAN, and cloud platform management
- Supports 802.3at PoE (48V) and 12V DC power
- Built-in lightning and surge protection
The APH5-AX830SFP is a dual-band Wi-Fi 6 outdoor access point delivering 3000Mbps (574 + 2402Mbps) with a dedicated Gigabit SFP port for fiber backhaul. Supporting up to 192 concurrent clients in an IP65-rated UV-resistant enclosure, it is designed for enterprise, campus, and ISP outdoor deployments where both performance and flexible backhaul options are required.
Ideal For
- Enterprise campus outdoor networks requiring fiber uplinks
- Hotels and resorts with extensive outdoor coverage areas
- ISP outdoor hotspot and last-mile deployment projects
- Industrial parks and factory outdoor networks
- Schools and universities with fiber-connected outdoor infrastructure
Deployment Advantages
The combination of a dedicated GbE SFP port alongside a 2.5GbE copper WAN port gives network architects full flexibility: connect via fiber for long-reach high-bandwidth uplinks or use standard PoE Ethernet for simpler deployments. This dual-interface design eliminates the need for media converters in fiber-to-AP segments, reducing installation complexity and failure points.
Four external omnidirectional antennas (5dBi per band) provide balanced 360° coverage across open outdoor spaces. Seamless roaming support ensures uninterrupted connectivity as users move between APs, while VLAN segmentation and cloud management provide the enterprise-level control required for multi-tenant or multi-site operations.
OEM/ODM Ready
MossLink offers OEM and ODM customization for this product, including custom firmware, SFP module selection, enclosure branding, and private-label packaging. Volume pricing is available for system integrators, ISPs, and enterprise resellers. MossLink is an access point OEM manufacturer in China shipping white-label APs with your branding and firmware. Contact us to discuss your project requirements.
Specifications
| Standard | Wi-Fi 6 (802.11ax) |
| Band | Dual-Band (2.4GHz + 5GHz) |
| Max Speed | AX3000 (574 + 2402 Mbps) |
| Antenna | 2×2.4GHz + 2×5GHz External Omni, 5dBi each |
| Ethernet | 1× GbE SFP + 1× GbE WAN (PoE 48V) + 1× GbE LAN |
| PoE | 802.3at (48V) |
| Max Clients | 192 |
| Enclosure | IP65 Outdoor Rated |
| Mounting | Pole / Wall Mount |
| Dimensions | 230 × 180 × 47.1 mm |
| Temperature | -30°C ~ +55°C |
| Power | 12V DC 2A / 802.3at PoE, < 20W |
Ordering & Customization
The APH5-AX830SFP ships factory-direct from Shenzhen with full OEM/ODM support. Three customization levels are available depending on your order quantity:
Logo & Packaging (OEM)
From 100 units
- Your logo on the enclosure
- Branded box, labels & user manual
- Zero MossLink branding on final product
Custom Firmware (Software)
From 500 units
- Custom web UI & boot screen
- Default configuration & feature tuning
- Regional and regulatory presets
Custom Hardware (ODM)
From 1,000 units
- Enclosure & antenna modifications
- Port and power-budget variations
- PCB-level customization
Learn more about our OEM/ODM process →
- Standard MOQ
- 100 units for standard products with no customization
- Samples
- 1–5 evaluation units at product cost plus shipping — sample fee credited toward your first bulk order
- Lead Time
- In-stock products: 3–5 business days · bulk production: 3–4 weeks · OEM/ODM orders: 4–8 weeks
- Payment Terms
- 30% deposit, 70% balance before shipment · T/T and L/C accepted, in USD
- Shipping
- DHL / FedEx / UPS express, air and sea freight · DDP, FOB Shenzhen, or CIF terms
- Packaging
- Each unit individually boxed with protective foam; palletized export cartons for freight — carton specs available on request
- Quality Control
- 100% inspection and 24-hour burn-in testing; a signed QC report ships with every order
- Certifications
- CE, FCC, and RoHS standard · additional market certifications (IC, TELEC, NCC, etc.) available via ODM
Downloads
Frequently Asked Questions
Why does the APH5-AX830SFP include an SFP port?
The Gigabit SFP port enables direct fiber connectivity for long-distance backhaul, providing higher bandwidth and stability compared to copper-only solutions. It is particularly useful for large campus deployments, ISP outdoor installations, and networks where fiber infrastructure already exists.
What deployments is the APH5-AX830SFP best suited for?
The APH5-AX830SFP is ideal for enterprise campuses, hotels with large outdoor areas, industrial parks, ISP outdoor hotspot projects, schools, and resorts — anywhere requiring reliable outdoor Wi-Fi with the option for fiber backhaul integration.
How many clients can this AP handle simultaneously?
The APH5-AX830SFP supports up to 192 concurrent clients, making it suitable for medium-to-large outdoor deployments such as hotel pools, campus open areas, or outdoor event venues.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
What is the MOQ for the APH5-AX830SFP?
Standard APH5-AX830SFP orders start at 100 units. Logo and packaging customization (OEM) also starts at 100 units, custom firmware at 500 units, and custom hardware (ODM) at 1,000 units. Contact sales with your target quantity for a formal quotation.
Can I get a sample of the APH5-AX830SFP before bulk ordering?
Yes. We supply 1–5 evaluation units at product cost plus shipping, and the sample fee is credited toward your first bulk order. Contact us via email or WhatsApp with the model number to arrange a sample.
What is the lead time for the APH5-AX830SFP?
In-stock units ship within 3–5 business days. Bulk production orders typically require 3–4 weeks, and OEM/ODM orders with customization take 4–8 weeks depending on complexity. Rush production is available at additional cost.
Is the APH5-AX830SFP certified for my market?
The APH5-AX830SFP carries CE, FCC, and RoHS certification as standard. Additional certifications for specific markets (IC, TELEC, NCC, etc.) can be arranged through our ODM service.
How is product quality controlled before shipment?
Every unit undergoes 100% inspection and 24-hour burn-in testing before leaving the factory, and a signed QC report ships with every order — full traceability from component to delivery.
What payment terms do you accept?
Standard terms are a 30% deposit with order confirmation and the 70% balance before shipment, paid in USD via T/T. Letter of credit and flexible terms are available for established partners.
