AX3000 Indoor Ceiling Mount Wi-Fi 6 Access Point, 256 Clients, PoE

AX3000-C

Type Indoor Ceiling Mount Access Point
Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (573 + 2402 Mbps)
CPU IPQ5018
View all specifications →

5 Years Warranty

Talk via WhatsApp

Specifications

Type Indoor Ceiling Mount Access Point
Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (573 + 2402 Mbps)
CPU IPQ5018
Max Clients 256 concurrent devices
PoE 802.3af/at
Ports 1× Gigabit Ethernet (PoE in)
Security WPA3, WPA2, WEP
Mounting Ceiling Mount
Dimensions 250 × 250 × 40 mm
Temperature -10°C ~ +50°C

Features

  • Wi-Fi 6 dual-band AX3000 — 573Mbps on 2.4GHz and 2402Mbps on 5GHz
  • Qualcomm IPQ5018 enterprise platform — low latency, high efficiency
  • Supports up to 256 concurrent devices with OFDMA and MU-MIMO
  • Single-cable installation via 802.3af/at PoE — no power outlet needed
  • WPA3 encryption with guest network isolation for secure multi-tenant use
  • Ceiling mount design for uniform 360° coverage across large indoor spaces
  • Cloud management and remote monitoring for multi-site deployments
  • Seamless roaming support for uninterrupted mobile user connectivity

The AX3000-C is a ceiling mount Wi-Fi 6 indoor access point powered by the Qualcomm IPQ5018 platform. It delivers dual-band AX3000 performance (573Mbps on 2.4GHz and 2402Mbps on 5GHz), supports up to 256 concurrent clients with OFDMA and MU-MIMO, and is powered via a single 802.3af/at PoE cable. Designed for hotels, schools, offices, and commercial venues, it offers WPA3 security, guest network isolation, seamless roaming, and cloud management in a clean ceiling mount form factor.

Ideal For

  • Hotel floor deployments requiring high-density per-room Wi-Fi coverage
  • School classrooms and dormitories with large numbers of student devices
  • Office open-plan areas and conference rooms with dense concurrent users
  • Retail stores, shopping malls, and hospitality venues with guest Wi-Fi
  • Managed service providers deploying multi-site enterprise wireless networks

Deployment Advantages

The single-cable 802.3af/at PoE connection simplifies installation — no separate power outlet or AC adapter needed. The ceiling mount 250×250mm form factor distributes signal evenly across the floor below, reducing the number of APs required per floor compared to wall-mounted alternatives.

The IPQ5018 platform handles up to 256 simultaneous connections without congestion through OFDMA scheduling, ensuring consistent throughput for video conferencing, streaming, and enterprise applications. WPA3 encryption and guest network isolation protect tenant and guest traffic on shared infrastructure.

OEM/ODM Ready

MossLink offers OEM and ODM customization for this product, including custom SSID management firmware, white-label cloud management platform integration, enclosure branding, and private-label packaging. Volume pricing is available for hotels, IT integrators, and enterprise wireless resellers. Contact us to discuss your project requirements.

Frequently Asked Questions

How many clients can the AX3000-C ceiling AP support simultaneously?
The AX3000-C supports up to 256 concurrent wireless clients across its dual-band radios. Qualcomm's IPQ5018 platform with OFDMA and MU-MIMO technology ensures stable per-device throughput even at full capacity, making it well suited for dense environments such as hotel floors, conference centres, schools, and open-plan offices.
What PoE standard does the AX3000-C require?
The AX3000-C is powered via IEEE 802.3af/at PoE, allowing both power and data to be delivered over a single Cat5e or better Ethernet cable. This eliminates the need for a local power outlet and simplifies ceiling installation in commercial spaces.
Does the AX3000-C support cloud management?
Yes. The AX3000-C is compatible with cloud management platforms, enabling centralised configuration, firmware updates, and real-time monitoring across multiple sites. IT administrators and managed service providers can manage large AP deployments remotely without on-site visits.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
